Solid State Relays and Devices
We manufacture the best and unique modules some for controlling DC and AC power and some for signal processing to enhance SNR. Among large
varieties of SPST, SPDT, DPST relays with MOSFET and IGBT on their output(s) you’ll find a relay to meet your specifications. From D1L-series
(a low cost, medium speed SSRs) to D3F-series (moderate costs and high-speed SSRs) devices are ready to switch various signals and drive
different kind of loads: AC and DC power, video, flashlamp for SS-laser, DC and stepper motors, solenoids, audio signal multiplexing, quartz,
lamps, coils, plasma, etc.
Read More
|
50/60Hz Notch Filter
The EDR 82534 is a low cost, multi-notch (comb) reject filter for low frequency signal applications. A Power interference
or band stop filter is an important and needed sub-component to design and build medical recording systems where minute
bioelectric signals, on the order of millivolts to microvolts are measured.
Read More
|
|  |
New Product Offerings
Super High-Power Switching Apparatus (SHPSA) with Virtual Battery.
Family of SHPSA has expended by delivering a more powerful device that generates up to 2,500 Amps /650V or 300kW (average) and 1.6MW pulses, assembled in a 19”W x 4’L x 6’H rock cabinet.
A controller PF-SPCO (P/N EDR89012) configures several SPST-NO switches (D9G650D103) rated at 1,000Arms & 650VDC as a single SPDT&N (or SPCO) switch with a neutral, break-before-make action.
An external pulse generator can be use for generating all kinds of waveforms. Inquiries are welcome for delivering schedule and prices. For your unique application that requires a different voltage,
current or speed, do not hesitate to send us an email to:
info@vsholding.com
SHPSA - Operation Manual
SHPSA - PRESS RELEASE
|
DIN Rail mounted Solid-State Relays/Switches and Drivers
Having a DIN Rail clamp makes things easier. Devices can easily be mounted or removed at any location on the DIN Rail thus installation or replacement is simple.
For your unique application that required a different voltage, current or speed, do not hesitate to send us an email to:
info@vsholding.com
Read More
|
Ultra-Fast I-V Biases Generators
are ultra-fast, bipolar pulse generating devices deliver bias voltages for controlling conductivity of high-voltage PIN diode during
Magnetic Resonance Imaging and Spectroscopy. For your unique application that required a different voltage, current or speed, do not hesitate to send us an email to:
info@vsholding.com
Read More
|
Super High-Power Switching Apparatus (SHPSA) with Virtual Battery. The SHPSA-200A400/100V05F has a Power
Rating of 80kW (average), 600kW pulse. Switches installed for handling 200VDC (140VAC) & 400Arms .
Built-in adjustable pulse generator, once triggered, would deliver a 10ms pulse.
For your unique application that required a different voltage, current or speed, do not hesitate to send us an email to:
info@vsholding.com
for any additional information, delivery schedule and prices.
Read More
|
UPEL-2500 Bench Top Electronic Load Simulation System. It is designed for DC/AC power sources, power electronic devices and
component testing. The high power rating, AC/DC capability, manual and remote controls make these loads the ideal tool for testing
the high power UUT such as SMR, UPS, telecommunications equipment manufacturers, power suppliers, drivers, battery and other power sources
that operate from DC to 100 KHz. For your unique application that required a different voltage, current or speed, do not hesitate to send
us an email to: info@vsholding.com for any additional information, delivery schedule and prices.
Read More
|
|
|
Press Release
|
Neural-Cell Technology
Electronic Design & Research Inc. introduces "The Super-High Resolution Electrocardiograph" SHR-EKG.
SHPSA-1000A650, mega power Solid State Switching Apparatus - PRESS RELEASE
Louisville, Kentucky, USA, – June 30, 2018 – Electronic Design & Research, Inc. announced the delivery of SHPSA-650A103F08, a 1,000 Amps Solid State Switching Apparatus (SHPSA) for various power tests to MET Laboratories, Inc.
Santa Clara, CA USA.
SHPSA-Operation Manual
Send us an email
Registered Trademark
Electronic Design & Research Inc. announced today of achieving a registered trademark on its logo from the United States Patent and Trademark Office.
DPDT-D relays
EDR/VSHOLDING extends a line of DIN rail mountable devices by introducing the DPDT (2C Form 2B) family of SSRs mimicking 100% comparable electromechanical relays.
Wide Hysteresis Window Comparator
DT1L's family - EDR/VSHOLDING announces the xTxL family of SSRs with high precision, wide hysteresis window comparator and varied contact forms rated at various voltages/currents.
Isolated Brushed DC Motor Drivers
iMDxx family - Isolated Brushed DC Motor / Piezo driver with Power Ratings up to 21KW - EDR/VSHOLDING introduces a new family of isolated Brushed DC Motor drivers based on H-bridge configuration can be
used for driving Brushed DC motors, power converging or driving a Piezo transducer with doubling power.
DIN Rail mounted Solid-State Relays/Switches and Drivers
EDR/VSHOLDING announces DIN Rail mounted SPST, SPDT, DPST, SPDT&N
Solid-State Relays/Switches and half & full-bridge drivers. A wide range of devices are available off the shelf and are rated at a variety of output voltages, output currents, input control voltages and power requirements.
900V High-Speed H-driver
EDR/VSHOLDING introduces 900 VDC / 9.5 kW 10 ns rise time Full-Bridge ISO-drivers
for applications where delivering kilowatts of high-frequency power is a must, such as a voltage booster to piezoelectric transducers and DC/DC converters, bidirectional PWM control, etc.
Ultra-Fast I-V Biases Generator
EDR, Inc/VSHolding is proud to announce the third generation Ultra-Fast I-V Biases Generators (UFBG) designed for real
-time MRI, Magnetic Resonance Spectroscopy (MRS) and Ultrashort TE (UTE) Imaging.
High Power Panel Mount Relay. up to 1500 VDC & 150 Amp. Low control power of only 1.4mW at 2.8 VDC.
EDR/VSholding Announces the first shipment of W1F30D14/5 highspeed DPST/SPDT relays/switches.
U.S. Patent Office - Notice of Publication of Application for the
"High Efficiency All-Electric Vehicle Propulsion System"
Micro-Power Solid-State Relays Output to 3.5kW of AC or DC voltages with a control of only 0.6mW.
Vladimir A. Shvartsman's book "How to Paint Chickens..." now on BookDaily.com
VSHolding relays used in KTH Racing's electric powered race car.
Reader Views - Interview
Pacific Book Review - Interview
